Fig. 5b. Asymmetric CT Specimen with Crack after Test. Effect of Ratio of Specimen Length / Crack Length on Crack Path Trajectories The ratio of the specimen length and the initial crack length (w/a) was expected to be important for crack stability. Accordingly, PMMA specimens with different values of w/a were tested. The crack length (a) was varied from 12.7mm (0.5’’), to 25.4mm (1’’), and 38.1mm (1.5’’) while the value of w=101.6 mm (4’’) was kept constant; thus w/a equaled 8, 4, and 2.67. The other dimensions were the same as those for the CT specimen. The crack paths are shown in Fig. 6. Fig. 6. Trajectories of the crack path of the specimens with different initial crack lengths (From top to bottom: a=12.7mm, 25.4mm, and 38.1mm.) 17
