96 K. A. Mac Donald and G. Ravichandran corresponding to a mean SIF (K) andERR(G) of 850Pa√mand6.9 J/m2 respectively. The estimated size of the nonlinear region near the crack tip (rNL) is 28μm, which corresponds to about 22 pixels in the captured images, roughly the size of an appropriate digital image correlation subset for this speckle pattern. Errors in these calculated values are comparable to the errors reported for more traditional fracture experiments in similar soft gel materials [9]. Some features of crack renucleation in this networked polymer hydrogel were observed at the submillimeter scale such as intact ligaments and indicators of local toughening. However, to better understand nonlinear processes in this gel, higher resolution imaging of the crack tip nonlinear region is needed. In this study, we were able to use crack geometry and the polymer’s material properties to determine traditional measures of fracture toughness without needing to define and measure complex boundary conditions. We were also able to determine the scale at which we would expect nonlinear processes to affect the crack. Acknowledgments This material is based upon work supported by the National Science Foundation Graduate Research Fellowship under Grant No. DGE-1144469 and the Designing Materials to Revolutionize and Engineer our Future (DMREF) program under Award No. DMS-1535083. Imaging was performed in the Biological Imaging Facility, with the support of the Caltech Beckman Institute and the Arnold and Mabel Beckman Foundation. Sandia National Laboratories is a multimission laboratory managed and operated by National Technology & Engineering Solutions of Sandia, LLC, a wholly owned subsidiary of Honeywell International Inc., for the US Department of Energy’s National Nuclear Security Administration under contract DE-NA0003525. References 1. Baldi, F., Bignotti, F., Peroni, I., Agnelli, S., Ricco, T.: On the measurement of the fracture resistance of polyacrylamide hydrogels by wire cutting tests. Polym. Test. 31(3), 455–465 (2012) 2. Gong, J.P., Osada, Y.: Soft and wet materials: from hydrogels to biotissues. In: Cloitre, M. (ed.) High Solid Dispersions, pp. 203–246. Springer, Berlin/Heidelberg (2010) 3. Long, R., Hui, C.Y.: Fracture toughness of hydrogels: measurement and interpretation. Soft Matter. 12(39), 8069–8086 (2016) 4. Moshayedi, P., Ng, G., Kwok, J.C.F., Yeo, G.S.H., Bryant, C.E., Fawcett, J.W., Franze, K., Guck, J.: The relationship between glial cell mechanosensitivity and foreign body reactions in the central nervous system. Biomaterials. 35(13), 3919–3925 (2014) 5. Coyle, S., Majidi, C., LeDuc, P., Hsia, K.J.: Bioinspired soft robotics: material selection, actuation, and design. Extrem. Mech. Lett. 22, 51–59 (2018) 6. Engler, A.J., Sen, S., Sweeney, H.L., Discher, D.E.: Matrix elasticity directs stem cell lineage specification. Cell. 126(4), 677–689 (2006) 7. Whang, M., Kim, J.: Synthetic hydrogels with stiffness gradients for durotaxis study and tissue engineering scaffolds. Tissue Eng. Regen. Med. 13(2), 126–139 (2016) 8. Yeung, T., Georges, P.C., Flanagan, L.A., Marg, B., Ortiz, M., Funaki, M., Zahir, N., Ming, W., Weaver, V., Janmey, P.A.: Effects of substrate stiffness on cell morphology, cytoskeletal structure, and adhesion. Cell Motil. 60(1), 24–34 (2005) 9. Agnelli, S., Baldi, F., Bignotti, F., Salvadori, A., Peroni, I.: Fracture characterization of hyperelastic polyacrylamide hydrogels. Eng. Fract. Mech. 203, 54–65 (2018) 10. Nilsson, F.: A tentative method for determination of cohesive zone properties in soft materials. Int. J. Fract. 136(1), 133–142 (2005) 11. Tanaka, Y., Shimazaki, R., Yano, S., Yoshida, G., Yamaguchi, T.: Solvent effects on the fracture of chemically crosslinked gels. Soft Matter. 12(39), 8135–8142 (2016) 12. Ahmed, E.M.: Hydrogel: preparation, characterization, and applications: a review. J. Adv. Res. 6(2), 105–121 (2013) 13. Denisin, A.K., Pruitt, B.L.: Tuning the range of polyacrylamide gel stiffness for mechanobiology applications. ACS Appl. Mater. Interfaces. 8(34), 21893–21902 (2016) 14. Odian, G.: Principles of Polymerization. Wiley InterScience Electronic Collection. Wiley, Hoboken (2004) 15. Brighenti, R., Spagnoli, A., Carpinteri, A., Artoni, F.: Notch effect in highly deformable material sheets. Thin-Walled Struct. 105, 90–100 (2016) 16. Naficy, S., Brown, H.R., Razal, J.M., Spinks, G.M., Whitten, P.G.: Progress toward robust polymer hydrogels. Aust. J. Chem. 64(8), 1007–1025 (2011) 17. Anderson, T.L.: Fracture Mechanics: Fundamentals and Applications, 3rd edn. CRC Press, Boca Raton (2005) 18. Rice, J.R.: A path independent integral and the approximate analysis of strain concentration by notches and cracks. J. Appl. Mech. 35(2), 379–386 (1968) 19. Shih, C.F.: Relationships between the J-integral and the crack opening displacement for stationary and extending cracks. J. Mech. Phys. Solids. 29(4), 305–326 (1981) 20. Geubelle, P.H., Knauss, W.G.: Finite strains at the tip of a crack in a sheet of hyperelastic material: I. Homogeneous case. J. Elast. 35, 61–98 (1994) 21. Mac Donald, K.A., Ravichandran, G.: Crack propagation and renucleation in soft brittle hydrogels. Int. J. Fract. 222, 37–52 (2020)
